CAVI ISOLATI IN PVC OMOLOGATI UL-CSA
PVC INSULATED CABLES UL-CSA APPROVED
CAVI PVC OMOLOGATI UL-CSA
   UL-CSA PVC WIRES
Cavi unipolari isolati in PVC
per il mercato Nord Americano.
Single-core PVC insulated wires for the north American market.
Configurazioni / Configurations
12
1 – Conduttore / Conductor 2–PVC
      Sezione / Size
AWG mm2
30 0,05
28 0,08
26 0,13
24 0,20
22 0,32
20 0,51
18 0,82
16 1,30
14 2,07
12 3,30
10 5,25
9 6,62
8 8,35
7 10,60
6 13,30
5 16,80
4 21,10
3 26,60
2 33,60
1 42,30
0 53,40
2/0 67,50
3/0 85,00
4/0 107,00
250 MCM 126,00
300 MCM 152,00
350 MCM 177,00
400 MCM 202,00
500 MCM 253,00
600 MCM 304,00
700 MCM 354,00
750 MCM 380,00
1039
15/12
15/12
15/12
15/12
15/12
80°C 90°C 105°C 300V 300V 300V
1497 1706 1569
1007
1011
80°C 600V
1013 1101
1498
31/28
31/28
31/28
31/28
31/28
31/28
31/28
31/28
31/28
   Spessore di isolamento / Insulation thickness (mils; 1 mils = 0,0254 mm)
     16/14
16/14
16/14
16/14
16/14
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
15/13
30/27 30/27
30/27 30/27
30/27 30/27
30/27 30/27
30/27 30/27
30/27 30/27
30/27 30/27
30/27 30/27
30/27 30/27
45/40 45/40
45/40 45/40
60/54 60/54
60/54 60/54
60/54 60/54
60/54 60/54
60/54 60/54
80/72 80/72
80/72 80/72
80/72 80/72
80/72 80/72
80/72 80/72
95/86 95/86
95/86 95/86
95/86 95/86
95/86 95/86
95/86 95/86
     15/13
15/13
15/13
                        Optional ---------
