 Sezione
Size
AWG mm2
30 0,05
28 0,08
26 0,13
24 0,20
22 0,32
20 0,51
18 0,82
16 1,30
14 2,07
12 3,30
10 5,25
9 6,62
8 8,35
7 10,60
6 13,30
5 16,80
4 21,10
3 26,60
2 33,60
1 42,30
0 53,40
2/0 67,50
3/0 85,00
4/0 107,00
250 MCM 126,00
300 MCM 152,00
350 MCM 177,00
400 MCM 202,00
500 MCM 253,00
600 MCM 304,00
700 MCM 354,00
750 MCM 380,00
300 V
150°C 600 V
200°C 300 V
APPLICAZIONI SPECIALI
SPECIAL APPLICATIONS
CAVI SILICONICI PER INDUSTRIA, POSA FISSA E ALTE TEMPERATURE
SILICON CABLES FOR INDUSTRY, FIXED INSTALLATION & HIGH TEMPERATURES
   CAVI SILICONE RIVESTITI CON CALZA,
 OMOLOGATI UL-CSA
SILICON BRAIDED UL–CSA APPROVED CABLES
Cavi unipolari isolati in gomma siliconica, rivestiti con treccia in fibra di vetro, per il mercato Nord Americano.
Single-core silicone rubber insulated cables, with external fiberglass braid for the North American market.
Configurazioni / Configurations 150°C
123
1 – Conduttore / Conductor
2 – Gomma siliconica / Silicone rubber
3 – Treccia in fibra di vetro / Fiberglass braid
      3068 3069 3070 3100 3101 3208 3207 3231 3278 3301 3605 3122 3508
    15/13 15/13 15/13 15/13 15/13 15/13 15/13 15/13
Spessore di isolamento / Insulation thickness (mils; 1 mils = 0,0254 mm) 30/27
  30/27 30/27 30/27 30/27
30/27
30/27
30/27
30/27
30/27
30/27
30/27
30/27
45/40
45/40
60/54 60/54 60/54 60/54 60/54 60/54 60/54 60/54 60/54 60/54 60/54 60/54 60/54 60/54 80/72 80/72 80/72 80/72 80/72 80/72 80/72 80/72 80/72 80/72 95/85
95/85 95/85 95/85 95/85 110/99 110/99 110/99
40/36 40/36 40/36 40/36 40/36 40/36 40/36 40/36
55/50 55/50 55/50 70/63 70/63 70/63 70/63 90/81 90/81 90/81
30/27
30/27 15/13 30/27 15/13 30/27 15/13 30/27 15/13 30/27 15/13 30/27 15/13 30/27
30/27
30/27
30/27
45/40
60/54
60/54
60/54
60/54
60/54
60/54
80/72
80/72
80/72
80/72
80/72
95/85
95/85
95/85
95/85
95/85
110/99 110/99 110/99
20/18 20/18 20/18 20/18 20/18
    30/27 30/27 30/27 30/27
60/54 60/54 60/54 60/54
60/54
   30/27
 45/40
